MT201
Fully managed in-vehicle device for HGV fleets
Safely and effectively connect with your drivers in the field, replace manual processes with digitised workstreams and increase productivity.
Improve Safety
Increase Productivity
Digital Processes
Manage Compliance
Key Features - Device & Software:
- Pre-trip inspection checklists
- Customisable forms
- Electronic in-cab documents
- Speed management
- Real-time route guidance
- Job management
- Instant messaging
- Driver identification
Key Features - Managed Service:
- Secured device
- Automatic updates
- Service desk access
- Device management
- Device provisioning
- Integration
- Device warranty
- Tracking and location
MT201
Technical Specifications
Certifications: CE/CB, FCC/IC, RCM, E-mark, ROHS, WEEE
Ratings: IP54, Vibration & Shock resistance: SAE J1455 standard, up to 20G peaks
LTE: LTE/3G/2G
WiFi: 802.11 a/b/g/n/ac (2.4/5Ghz)
Bluetooth: BT 4.2+BLE
GNSS: GPS+AGPS, GLONASS, QZSS
CPU: Qualcomm SDM 450
Memory Storage: 4GB / 64GB, microsSD Expansion
Display: 7”, 600x 1024 pixels
Touchscreen: Anti-glare, Capacitative, Multi-point
Battery: 4,000mAh Li-ion Polymer, Battery life 8+ hours depending on usage
Operational Voltage: 9˜32V wide DC input
Current Consumption at 12V: Awake, idle ~250mA, Battery Charging ~1A
Cameras: Front: 8MP AF, Rear: 8MP AF with Flash
Microphone, Speaker: 2x Built-in microphones, 1x Built-in speaker
I/O Ports: 6-pin fleet port (Tx/Rx, 12/24V, IGN), Type C USB 2.0 port
Sensors: NFC sensor, Light sensor
Operating Temperature: -20°C to +60°C (-4° to +140°F) operating
Size: Height: 132mm, Width: 210.80mm, Depth: 20.55mm
Weight: 480g
Firmware Updates: Over-the-air (OTA)
Supported Platforms: DIRECTOR, TN360
Easy Docs: Electronic documents available 24/7 – reduce the paperwork required to be stored in the vehicle.
Smart Jobs: Send daily run sheets and one off jobs to your drivers and stay on schedule with turn by turn navigation, clear job instructions and proof of delivery (signature and photo).
Messaging: Instant driver-dispatch communication and manager-based routing messages for immidiate in-cab updates.
Journey Planner (in. Smart Nav Route): Create smarter, more specific routes that include all scheduled stops and waypoints and provide drivers with turn-by-turn navigation to their destination following the specified route.
Forms: Paperless, customisable forms for receiving & tracking information across the business in real-time.
Pre-trip Checklist: Create any number of checklists for driver and vehicle safety and compliance.
Driver Scorecard: Keep an eye on driver performance and safety via a number of metrics.
Your Success
Intelligent support every step of the way
Our focus is on helping you to realize your goals and our professional services, training and customer support teams are there to help ensure you maximize the impact of your solution.
